CV832-3003

• Engine Series: Kohler Command Pro Series
• Power Rating: 32
• Valve Type: Overhead Valve
• Sleeved Bore: Yes
• Mounting: Vertical
• Engine Displacement (cc): 888
• Starter Type: Electric Start
• Alternator: 20 Amp
• Oil type: Rehlko (Kohler) 4 Cycle 10W-40 Synthetic (OCK-RKB-10540)
• Oil Refill Capacity: 2.0 qt (1.9 L)
• Shaft Size: 1-1/8"Dx4-5/16"L
• Fuel Tank Capacity: None
• Fuel Pump: Yes
• Oil Cooler: Yes
• Muffler: Not Included
• Throttle Type: Remote
• Choke Type: Remote
• Item Length: 20"
• Item Height: 24"
• Item Width: 13.8"
• Shipping Rate Weight: 170
• Product Condition: New
• Warranty: 3-Year Engine Manufacturer Warranty
• Country of Origin: United States of America
• Item cannot be shipped to these states: California

Additional Specifications

• 6-inch heavy-duty air filter longer maintenance interval
• Fuel-pressure lubricant with full-flow filter
• Optional oil cooler to maintain low temperatures during the entire power range
• Chopper grass screen
• Easily removable cleanout covers: improved cooling and extended engine life
• 20-amp sealed charging regulated: over-voltage protection
• EMC and RFI Compliant
• Resuse Muffler if directly replacing 824 Series
• Muffler Options: KO-1906811S (flush mount starter side); KO-1906812S (flush mount oil filter side); KO-1978605S (low mount)
• Accessories: KO-2413909S M18 02 Sensor Muffler Plug; KO-2517622S Jumper Wire Harness;

Fits These Models

• Shivvers-CC 824 Charger and Boss XL
• Moridge 824 300G Series (use muffler 101201)
• Bad Boy Rogue (use muffler 015-01012-00)
• Excel Super Z - ECV880 (use muffler 605828)
• Excel - X One Commercial X-One 52", 60", & 72" (use muffler 605828)
• 824 Gravely ProTurn 400 (use Kohler muffler 19 068 08)

Replaces These Items

• ECV880-3035; ECV860-3028; ECV880-3033; ECV880-3031; ECV860-3019; ECV880-3022
