CH730-3225

LP#: CH7303225
23.5hp Command OHV Hor 1-1/8"x2-3/4" Shaft, exact for Exmark, Muffler, replaces spec 68606 68543, CH730-0003 Kohler Engine
$2,339.00

OUT OF STOCK

Temporarily out of stock. Order now or call 800-222-4303 for information

Additional Shipping Cost $139.99
(Maximum surcharge listed. See actual total in cart.)

Item Specifications

Item Specifications

  • 23.5hp
  • Oil Filter & Cooler
  • Valve Type: Overhead Valve
  • Sleeved Bore: Yes
  • Mounting: Horizontal
  • Starter Type: Electric Start
  • Alternator: 15 Amp
  • Shaft Size: 1-1/8"Dx2-3/4"L
  • Muffler: Right Side
  • Shipping Rate Weight: 151
  • Product Condition: New
  • Warranty: 3-Year Manufacturer's Warranty

Notes and Warnings
  • The gross power rating is measured in accordance with SAE J1995 at 3600 rpm (without the muffler and air filter in place). Torque values are derived at 2600 rpm. Actual power output for the engine installed in the final machine will vary depending on numerous factors, including the operating speed of the engine in application, environmental conditions, maintenance, and other variables.

Additional Specifications
  • 23.3hp Horizontal Kohler Engine
  • 3-year Consumer/Commercial Warranty
  • Shipping weight: 117lbs
  • Displacement: 725cc
  • Electric Start
  • Fuel: Gasoline
  • Crankshaft type: Straight
  • Gear reduction: No
  • 1-1/8" x 2.79" Crankshaft
  • Crankshaft end tapped size: 7/16 - 20
  • 1/4"W Crankshaft Keyway
  • Crankshaft Rotation (from PTO side): Counterclockwise
  • Dual Cylinder
  • Cast Iron Bore
  • Air cleaner: None, remote mount
  • Fuel pump: Yes
  • Oil cooler: Yes
  • Low oil alert: None
  • Low oil shutdown: None
  • Electronic Ignition system
  • Carburetor type: Accelerator pump
  • Choke control: Remote
  • PTO height: 6-1/8"
  • *Additional freight charges apply

Fits These Models
  • Exmark

Replaces These Items
  • PA-68543; PA-68606; PA-CH730-0003; PA-68695
