GX390XQA
LP#: GX390QA
11.7 Net Power Honda Engine, Horizontal 1"x3-21/32" Keyed Shaft, Recoil Start (49-state emissions)
Additional Shipping Cost $65.99
(Maximum surcharge listed. See actual total in cart.)
Item Specifications
Item Specifications
- Honda GX Commercial Series
- 11.7 Net Power
- Valve Type: Overhead Valve
- Sleeved Bore: Yes
- Mounting: Horizontal
- Engine Displacement (cc): 389
- Starter Type: Recoil Start
- Alternator: None
- Low Oil Shutdown: Yes (Low oil sensor may have to be disconnected to prevent engine stops during angled operation equipment like tillers.)
- Oil Capacity: 1.16 Quart
- Oil type: SAE 10W-30
- Shaft Size: 1"Dx3-21/32"L
- Muffler: Included
- Throttle Type: Manual
- Choke Type: Manual
- Length: 13.5"
- Height: 17.2"
- Width: 17.4"
- Shaft Height above Mounting Base: 5.25"
- Item Dry Weight: 69
- Shipping Rate Weight: 85
- Product Condition: New
- Warranty: 3-Year Manufacturer's Warranty
- Manufacturer Country: Thailand
- Item cannot be shipped to these states: California
Notes and Warnings
- Authorized Honda Dealer
- Mounting holes are 3.35" x 7.67" These are the Red/White color combination, all the mechanical features are the same as the all-black GX390QA-B
- The net power rating is measured in accordance with SAE J1349 at 3600 rpm (with the muffler and air filter in place). Actual power output for the engine installed in the final machine will vary depending on numerous factors, including the operating speed of the engine in application, environmental conditions, maintenance, and other variables.
