GX270XRA
8.5 Net Power Honda Engine, Horizontal 22MM Keyed Shaft, 2:1 Gear Reduction with wet clutch, Rev Limiter (49-State Emissions)
Additional Shipping Cost $64.99
(Maximum surcharge listed. See actual total in cart.)
Item Specifications
Item Specifications
- Honda GX Commercial Series
- 8.5 Net Power
- Valve Type: Overhead Valve
- Sleeved Bore: Yes
- Mounting: Gear Reduction
- Engine Displacement (cc): 270
- Starter Type: Recoil Start
- Alternator: None
- Low Oil Shutdown: Yes (Low oil sensor may have to be disconnected to prevent engine stops during angled operation equipment like tillers.)
- Oil Capacity: 1.16 Quart
- Oil type: SAE 10w-30
- Shaft Size: 22mmDx2"L
- Gear Reduction: 2:1 Clutch
- Muffler: Included
- Throttle Type: Manual
- Choke Type: Manual
- Length: 17.5"
- Height: 16.3"
- Width: 16.5"
- Shipping Rate Weight: 83.3
- Product Condition: New
- Warranty: 3-Year Manufacturer's Warranty
- Item cannot be shipped to these states: California
Notes and Warnings
- CLUTCH ENGAGEMENT OCCURS AT 1800RPM AT CRANKSHAFT, LOCK OCCURS AT 2200RPM The new UT2 engines have a built in rev limiter [ 4000 rpm max] in the Ign. Coil, the system has also changed from an open to run to a closed to run system. Along with going to a Digital CD system instead of a transistor system. The ignition systems cannot be changed or modified as this change was done to meet and comply with current EPA guidelines
- The net power rating is measured in accordance with SAE J1349 at 3600 rpm (with the muffler and air filter in place). Actual power output for the engine installed in the final machine will vary depending on numerous factors, including the operating speed of the engine in application, environmental conditions, maintenance, and other variables.
Fits These Models
- Go-Kart
